4
PoE
Ports
2
Uplink
Ports
60W
Power
2.0
Gbps
Capacity
Advanced Features
Fixed Port
4x10/100M PoE Switch Base-T/TX(PoE+port(Data/Power))
2x10/100Base-T/TX(Data/RJ45/Uplink/Data)
PoE Port
Port 1-4 support PoE
Ethernet Port Feature
10/100Base-T(X) automatic detection, full/half Duplex MDI/MDI-X adaptive
Fiber Port Feature
Store and forward
MAC
2K
Network Protocol
IEEE802.3 10BASE-T, IEEE802.3u 100Base-TX, IEEE802.3x
Switching Capacity
2.0Gbps
Forwarding Mode
0.89Mpps
Buffer Memory
768K
Twisted Pair Transmission
10BASE-T: Cat5 UTP(≤100 meter)
100BASE-TX Cat5 or later UTP(≤100 meter)
Power Supply Pin
Default 1/2(+), 3/6(-)
MAX/AVERAGE Power Per Port
30W/15.4W
Total PWR/Input Voltage
60W (52VAC)
Power Consumption
Standby:<2W/Full load:<60W
LED Indicator
Power indicator: PWR (Green)
Network indicator: 1-4(Link/Act)/ (Green),5-6(Link/Act)/ (Green)
Working Environment
-20°~+55°C,≤90% RH non condensing
Storage TEMP/Humidity
-40°~+75°C,≤90% RH non condensing
Dimensions
195×135×45mm
Net/Gross Weight
≤0.8kg / ≤1.2kg
Protection
IEC61000-4-2(ESD): ±8KV contact discharge, ±15KV air discharge
IEC61000-4-5(Lightning protection/Surge): Power:±2KV/4KV(DM/CM)24V, Port: ±4KV
